200 Standard Series - AL2

Manual Push Up System

The 200 Standard Series - AL2 is a lightweight, highly versatile manual push-up mast system featuring a patented cam lock tripod and 2-inch outer diameter interlocking aluminum alloy sections. Spanning model heights from 2 to 10 meters and supporting payloads from 20 to 100 lbs., it provides ground forces with a reliable, rapidly deployable platform for video surveillance, tactical RF communications, HF long wire setups, and hybrid operations in austere environments.

Model Heights:

2 to 10 meters (7.5 ft to 31.5ft)

Payload Capacity:

See capabilities chart

(See Capabilities Chart)

Wind Loading:

70 mph

Deployment Time:

1 to 2

people;

2 to 30 minutes

Outside Diameter:

2.0 inches

Testing: MIL-STD-810G

Transport:

(1) Custom 54 x 14 x 14 inch wheeling carry bag | (optional) Hard Case Upgrade 62 x 21 x 14 inches

Features:

Patented tripod design with cam lock system
Telescoping tripod legs
Compass and bubble levels
Lightweight 2in. OD interlocking mast sections
Aerospace aluminum alloy construction
Color coded, free spinning guy rings for directional control
Guy ropes made of Spectra Cord, a woven fiber 10 times stronger than common cable

Primary Uses:

Tactical RF communications
Wireless data
UAS / cUAS
Custom applications

Accessories Guide

Product Brochure

Load Tables

Quick Reference Sheet

User Manual

Training Video

Key Capabilities

Elevated Video Surveillance and Reconnaissance: Provides a rigid, elevated optical platform for tactical PTZ and thermal cameras, securing high-vantage situational awareness for border monitoring and fixed-site security.

HF Long-Wire Antenna Deployment: Serves as a reliable structural anchor for long-wire high-frequency antenna arrays, extending critical beyond-line-of-sight HF communication ranges in austere environments.

Rapid Tactical RF Integration: Elevates tactical radios, electronic warfare sensors, and communication antennas above ground clutter to optimize signal propagation and maintain robust unit connectivity.

Hybrid Multi-Mission Support: Adapts flexibly to diverse operational requirements by accommodating combined observation and wireless data payloads up to 100 lbs (depending on height configuration).

Capabilities Chart

The payload is the total weight of all devices, accessories, and cabling being mounted on the mast.

System P/N	System Height (Feet)	System Height (Meters)	Payload (lbs)	Payload (kg)
BSM2-M-M202-AL2-000	7.5	2	61.1	27.7
BSM2-M-M203-AL2-000	10.5	3	64.2	29.1
BSM2-M-M204-AL2-000	13.5	4	67.3	30.5
BSM2-M-M205-AL2-000	16.5	5	70.5	32
BSM2-M-M206-AL2-000	19.5	6	73.6	33.4
BSM2-M-M207-AL2-000	22	7.5	8.8	37.6
BSM2-M-M208-AL2-000	25.5	8	86	39
BSM2-M-M209-AL2-000	28.5	9	89.2	40.5
BSM2-M-M210-AL2-000	31.5	10	92.4	41.9

Capabilities Chart
BSM2-M-M202-AL2-000	System Height (ft)	7.5	System Height (m)	2	Payload (lbs)	61.1	Payload (kg)	27.7	BSM2-M-M203-AL2-000	System Height (ft)	10.5	System Height (m)	3	Payload (lbs)	64.2	Payload (kg)	29.1	BSM2-M-M204-AL2-000	System Height (ft)	13.5	System Height (m)	4	Payload (lbs)	67.3	Payload (kg)	30.5	BSM2-M-M205-AL2-000	System Height (ft)	16.5	System Height (m)	5	Payload (lbs)	70.5	Payload (kg)	32	BSM2-M-M206-AL2-000	System Height (ft)	19.5	System Height (m)	6	Payload (lbs)	73.6	Payload (kg)	33.4	BSM2-M-M207-AL2-000	System Height (ft)	22	System Height (m)	7.5	Payload (lbs)	8.8	Payload (kg)	37.6	BSM2-M-M208-AL2-000	System Height (ft)	25.5	System Height (m)	8	Payload (lbs)	86	Payload (kg)	39	BSM2-M-M209-AL2-000	System Height (ft)	28.5	System Height (m)	9	Payload (lbs)	89.2	Payload (kg)	40.5	BSM2-M-M210-AL2-000	System Height (ft)	31.5	System Height (m)	10	Payload (lbs)	92.4	Payload (kg)	41.9

200 Standard Series - AL2

Manual push up system

Designed for portability, rapid deployment, & heavier payloads
